✨✨✨ Specifications ✨✨✨
📌 Type – ATX12V V3.0
📌 Product Dimensions – 150×160×86mm (W x L x H)
📌 Efficiency certification – 80Plus GOLD/Cybenetics_Platinum
📌 Fan Size – 135mm
📌 Fan Bearing – FDB (Fluid Dynamic Bearing)
📌 Topology – Active PFC + Half Bridge SRC LLC + DC to DC
📌 Capacitors – Full Japan Electrolytic Capacitors
📌 Power Good Signal – 100-150ms
📌 Hold Up Time – ≥16ms
📌 Efficiency
🔹 ≥90% Under Typical
🔹 Load(50% Loading)
📌 Protection – OPP/OVP/SCP/OTP/OCP/UVP
📌 Operation Temperature – 0 – 40℃
📌 Regulatory
🔹 CE/FCC/CCC/TUV-RH/RCM/EAC/CAN ICES-003(B)/NMB-003(B)/UKCA/BIS/KC;
📌 Erp Regulation – ErP 2014
📌 Environment Protection – WEEE/中国 RoHS/Triman
📌 MTBF – 100,000 Hours
