❇️❇️❇️ Specifications ❇️❇️❇️
🔻 Mechanical 🔻
💠 Dimensions – 98 x 98 x 30 mm (3.6 x 3.6 x 1.2″)
💠 Weight – 302 g (10.7 oz)
💠 Enclosure material – Polycarbonate
🔻 Hardware 🔻
💠 Management interface – Ethernet, Bluetooth
💠 Networking interface – LAN: (1) GbE RJ45 port, WAN: (1) GbE RJ45 port
💠 Power method – USB type C (5V DC/3A)
💠 Max. power consumption – 10W
💠 Max. TX power
🔹 2.4 GHz – 22 dBm
🔹 5 GHz – 25 dBm
💠 MIMO
🔹 2.4 GHz – 2 x 2 (DL/UL MU-MIMO)
🔹 5 GHz – 2 x 2 (DL/UL MU-MIMO)
💠 Throughput rate
🔹 2.4 GHz – 573.5 Mbps
🔹 5 GHz – 2.4 Gbps
💠 Antenna gain
🔹 2.4 GHz – 4 dBi
🔹 5 GHz – 5.15 dBi
💠 Antennas
🔹 (2) Internal 2.4G/5G WiFi dual-band antenna
🔹 (1) Internal 2.4G single-band BT antenna
💠 LCM display – 0.96″ status display
💠 Button – Factory reset
💠 Ambient operating temperature – -10 to 45° C (14 to 113° F)
💠 Ambient operating humidity – 5 to 95% noncondensing
💠 Certifications – CE, FCC, IC
🔻 Gateway Features 🔻
💠 Performance – Internet quality and outage reporting
💠 Next-generation security – Application-aware firewall rules
🔹 Content, country, domain, and ad filtering
🔹 VLAN/subnet-based traffic segmentation
🔹 Full stateful firewall
💠 Advanced networking – License-free SD-WAN
🔹 WireGuard, L2TP and OpenVPN server
🔹 OpenVPN client
🔹 OpenVPN and IPsec site-to-site VPN
🔹 One-click Teleport VPN
🔹 Policy-based WAN and VPN routing
🔹 DHCP relay
🔹 Customizable DHCP server
🔹 IGMP proxy
🔹 IPv6 ISP support
🔻 Software 🔻
💠 WiFi standards – 802.11a/b/g/n/ac/ax
💠 Wireless security – WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
💠 BSSID – Console mode: 3 per band, Standard AP: 8 per band
💠 VLAN – 802.1Q
💠 Advanced QoS – Per-user rate limiting
💠 Guest traffic isolation – Supported
💠 Concurrent clients – 50+*
*Performance may be degraded with advanced gateway features (e.g., Traffic Identification).
🔻 Supported Data Rates 🔻
💠 802.11a – 6, 9, 12, 18, 24, 36, 48, 54 Mbps
💠 802.11b – 1, 2, 5.5, 11 Mbps
💠 802.11g – 6, 9, 12, 18, 24, 36, 48, 54 Mbps
💠 802.11n (WiFi 4) – 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40)
💠 802.11ac (WiFi 5) – 6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80/160)
💠 802.11ax (WiFi 6) – 7.3 Mbps to 2.4 Gbps (MCS0 – MCS11 NSS1/2, HE 20/40/80/160)
