TP-Link SG6654X Omada 48-Port Gigabit Stackable L3 Managed Switch ของแท้ ประกันศูนย์ Lifetime Warranty

✅ มีการรับประกันศูนย์ Lifetime Warranty

✅ สามารถออกใบกำกับภาษีได้

✅ 48× Gigabit RJ45 ports and 6× 10 Gbps SFP+ slots

✅ 216 Gbps switching capacity per unit

✅ Physical Stacking for built-in redundancy and performance

✅ L3 features: RIP, OSPF, ECMP, VRRP, PIM-DM, DHCP Server/Relay

✅ Security Strategies: ACL, Port Security, DoS Defend, 802.1X

✅ Highly Available with two internal fixed power supplies, VRRP, and ERPS

✅ Centralized cloud management via Omada SDN controller

✅ Standalone management via web, CLI, SNMP, and RMON

✨✨TP-Link SG6654X Omada 48-Port Gigabit Stackable L3 Managed Switch ของแท้✨✨

Omada SG6654X, a L3 managed switch, offers L3 routing, swift 10 Gbps wired speed, stacking, and redundant power supplies, catering to convergence layer demands. It comes with 48× gigabit RJ45 ports, 6× 10 Gbps SFP+ slots, and physical stacking. Integrated with robust security and comprehensive management features, this switch ensures reliable performance for SMB, enterprise, and ISP networks.

🌺High-speed Connectivity and Powerful Stacking

48× Gigabit RJ45 ports and 6× 10 Gbps SFP+ slots provide up to 216 Gbps switching capacity per unit. Up to 4 units of physical stacking with up to 864 Gbps switching capacity empower the networking structure with built-in redundancy and performance.

🌺Abundant Layer 3 Capabilities

Comes with abundant Layer 3 routing protocols that support a scalable network. Static Routing, RIP, OSPF, ECMP, VRRP, DHCP Server, and DHCP Relay are supported. PIM-DM multicast routing protocol guarantees efficient routing for multicast groups.

🌺Highly Available

Internal fixed redundant power supplies and VRRP make it an ideal choice for reliable networking architecture. ERPS supports rapid protection and recovery in a ring topology.

🌺Enhanced Security Functions

Defend against a range of network threats with ACL support (IPv4 & IPv6), Dynamic ARP Inspection, IEEE 802.1X, MAB, Port Security, and Secure Shell.

🤩🤩Specifications🤩🤩

⭐HARDWARE FEATURES

🚩Interface

• 48× 10/100/1000 Mbps RJ45 Ports

• 6× 10G SFP+ Slots

• 2× USB 2.0 Ports

• 1× RJ45 Console Port

• 1× USB Type-C Console Port

• 1× RJ45 Management Port

🚩Fan Quantity Four Internal Fixed Fans

🚩Power Supply Two Internal Fixed Power Supply Modules (100–240 VAC, 50/60 Hz)

🚩Dimensions ( W x D x H ) 17.3 × 15.0 × 1.7 in (440 × 380 × 44 mm)

🚩Mounting Rackmountable

🚩Max Power Consumption 39.8 W (220 V/50 Hz)

🚩Max Heat Dissipation 135.81 BTU/hr (220 V/50 Hz)

⭐PERFORMANCE

🚩Switching Capacity 216 Gbps per Unit

🚩Stacking

• Stacking Number: 4

• Stacking Port: 10G SFP+ Slot (all uplink ports can be used as stacking ports)

• Stack Bandwidth: 20 Gbps Per Port (Full-Duplex)

🚩Packet Forwarding Rate 160.7 Mpps

🚩MAC Address Table 32 K

🚩Packet Buffer Memory 3 MB

🚩Jumbo Frame 9 KB
